Galvanized Steel Iron Door Frame Making Machine PLC Control 18 Stations

Name: Galvanized Steel Iron Door Frame Making Machine PLC Control 18 Stations
Brand: Sussman
Price: 1 USD

Buy cheap Galvanized Steel Iron Door Frame Making Machine PLC Control 18 Stations product

Brand Name : Sussman

Model Number : SM-DP

Certification : CE

Place of Origin : Wuxi Jiangsu China

MOQ : 1 set

Price : negotiable

Payment Terms : T/T L/C

Supply Ability : 10 sets per months

Delivery Time : 60days after deposit

Packaging Details : Standard packing

Name : Door Panel Roll Forming Machine

Material : Galvanized steel

material thickness : 1.5-2.0mm

Forming stations : about 18 stations

Roller material : Gcr15, Quench HRC58-62 Plated Chrome

Dirve system : Gearbox

power supply : 380V, 50Hz, 3Phase

Forming speed : 12-15m/min

Machine weight : about 12 tons

Machine Size : 8m*1.5m*1.5m

Contact Now

Galvanized Steel Iron Door Frame Making Machine PLC Control 18 Stations

Technical Parameter

1. Suitable Plate Material: thickness 1.5-2.0mm, Galvanized steel or blank steel

2. Working Speed: 12-15 meters / min

3. Forming Steps: 18 stations

4. Material of Roller: Gcr15, Quench HRC58-62 Plated Chrome

5. Material of Shaft: 45# Advanced Steel (Diameter: 76mm), thermal refining

6. Driven system: gear box drive

7. Main Power with reducer:15KW WH Chinese Famous

8. Cutting: Hydraulic Cutting Cr12mov

9. Material of Cutting Knife: Cr12Mov, Quench HRC58-62

10. Hydraulic Station Power: 7.5KW Wuxi Wanshen Famous Chinese Brand

11. The whole machine is controlled by industry computer-PLC.

12 PLC--English and Chinese and Spanish Language or customized

13. Encoder--Omron, Japan

14. Electric parts--Schneider

Main Components

Serial No.	Commodity & Description	Quantity
1	5T manual uncoiler	1 set
2	Leveing guiding	1 set
3	Servo feeding device	1 set
4	Main roll forming machine	1 set
5	Punching Device	1 set
6	Cutting device	1 set
7	Finished products tabel	1 set
8	PLC control system	1sets
9	Out tables	1 sets
10	Spare parts	1 sets

Working Flow of Roll Forming Machine

Uncoiling—Feeding&Leveling--Punching Device---Roll forming—Cutting—Products collecting

Galvanized Steel Iron Door Frame Making Machine PLC Control 18 Stations

Profile of product

Galvanized Steel Iron Door Frame Making Machine PLC Control 18 Stations

Photo Gallery

Galvanized Steel Iron Door Frame Making Machine PLC Control 18 Stations

Product Tags:

sheet metal roll forming machines

Cold Roll Forming Equipment

Galvanized Steel Iron Door Frame Making Machine PLC Control 18 Stations Images
